Vapcell 3.2V P62 32700 6200mah 20A

Brand Vapcell
Series 32700
Model P62
Color black
Weight 150g
Chemistry IFR
Type flat top
Aliexpress Buy

Vapcell 3.2V P62 IFR32700 6200mah 20A


u Model: P62

u Size: 32.3±0.2*70.6±0.3mm

u Typical Capacity: 6200mAh (0.2C discharge)

u Min capacity: 6000mAh (0.2C discharge)

u Nominal voltage: 3.20V

u Max Continuous Discharge Current: 20A

u Max Pulse Discharge Current: 40A for 5seconds

u End-of-charge voltage: 3.65V

u End-of-discharge Voltage: 2.0V

u Weight: Max 150g

u Internal resistance: Max 11mΩAC 1kHz

u Standard Charge: 6000mA,CCCV 200mA cut-off

u Quick Charge Current: 15000mA


Button top can be added, and the size is 2-3mm longer than a standard 32700 cell like flat top & unprotected. The button top is widely required for flashlights, doorbells and other devices.
